Technical Spec
| Type | ATX12V V3.1 |
| Product Dimensions | 150×150×86mm (W x L x H) |
| Efficiency certification | 80Plus Gold |
| Fan Size | 135mm |
| Fan Bearing | FDB (Fluid Dynamic Bearing) |
| Topology | Active PFC + Half Bridge SRC LLC + DC to DC |
| Capacitors | Japanese Bulk Capacitor |
| Power Good Signal | 100-150ms |
| Hold Up Time | ≥16ms(80% Load) |
| Efficiency | ≥90% Under Typical Load(50% Loading) |
| Protection | OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO |
| Operation Temperature | 0 - 40℃ |
| Regulatory | CE/FCC/CCC/TUV-RH/cTUVus/RCM/EAC/BIS |
| Erp Regulation | ErP 2014 |
| Environment Protection | WEEE/中国 RoHS/Triman/P65 |
| MTBF | 100,000 Hours |
| EAN P/N | 6933412719717 R-PNA00M-FC0B-CN 6933412719724 R-PNA00M-FC0B-AU 6933412719731 R-PNA00M-FC0B-EU 6933412719748 R-PNA00M-FC0B-JP 6933412719755 R-PNA00M-FC0B-UK 6933412719762 R-PNA00M-FC0B-US 6933412719779 R-PNA00M-FC0B-IN 6933412719786 R-PNA00M-FC0B-WO 6933412719793 R-PNA00M-FC0B-BP |
