描述
|
|
|
Intel LGA2066, LGA2011-0 & LGA2011-3 (Square ILM), LGA1156, LGA1155, LGA1151, LGA1150 & AMD AM2, AM2+, AM3, AM3+, FM1, FM2, FM2+ (backplate required), AM4 (included since 2019, older coolers require NM-AM4-UxS)
|
|
|
Height (without fan)
125 mm
|
|
|
Width (without fan)
95 mm
|
|
|
Depth (without fan)
68 mm
|
|
|
Weight (without fan)
524 g
|
|
|
Height (with fan)
125 mm
|
|
|
Width (with fan)
95 mm
|
|
|
Depth (with fan)
95 mm
|
|
|
Weight (with fan)
618 g
|
|
|
Material
Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating
|
|
|
Max. TDP
|
|
|
Fan compatibility
92x92x25
|
|
|
Scope of delivery
|
|
|
6 Years
|
|
||
|
Model
|
||
|
Bearing
|
||
|
Max. rotational speed (+/- 10%)
2000 RPM
|
||
|
Max. rotational speed with L.N.A. (+/- 10%)
1550 RPM
|
||
|
Min. rotational speed (PWM, +/-20%)
400 RPM
|
||
|
78,9 m³/h
|
||
|
Max. acoustical noise
22,8 dB(A)
|
||
|
Max. acoustical noise with L.N.A.
16,3 dB(A)
|
||
|
Input power
1,2 W
|
||
|
Voltage range
12 V
|
||
|
MTTF
> 150.000 h
|
