Product Specifications
| Module Type |
DDR5 288 Pin Non-ECC Unbuffered DIMM |
||||||||||
| Frequency | 7600 | 7200 | 7000 | 6800 | 6600 | 6400 | 6200 | ||||
| Latency | CL36-46-46-84 | CL34-42-42-84 | CL34-42-42-84 | CL34-44-44-84 | CL34-40-40-84 | CL40-40-40-84 | CL38-38-38-78 | ||||
| Capacity | 16GBx2 | 16GBx2 | 16GBx2 | 16GBx2 | 16GBx2 | 16GB 16GBx2 |
16GB 16GBx2 |
||||
| Data Transfer Bandwidth | 60,800 MB/s (PC5 60800) |
57,600 MB/s (PC5 57600) |
56,000 MB/s (PC5 56000) |
54,400 MB/s (PC5 54400) |
52,800 MB/s (PC5 52800) |
51,200 MB/s (PC5 51200) |
49,600 MB/s (PC5 49600) |
||||
| Voltage | 1.4 V | 1.4 V | 1.4V | 1.4V | 1.4V | 1.35 V | 1.25 V | ||||
| Compatibility | Intel: 700 series | Intel: 600 series, 700 series | |||||||||
| Dimensions | 46.1(H) x 144.2(L) x 7(W)mm | ||||||||||
| Warranty | Lifetime warranty | ||||||||||
| Module Type |
DDR5 288 Pin Non-ECC Unbuffered DIMM |
|||||||||
| Frequency | 6000 | 6000 | 5600 | 5600 | 5600 | 5200 | ||||
| Latency | CL38-38-38-78 | CL30-36-36-76 | CL32-36-36-76 | CL36-36-36-76 | CL40-40-40-84 | CL40-40-40-76 | ||||
| Capacity | 16GB 16GBx2 |
16GB 16GBx2 |
16GB 16GBx2 |
16GB 16GBx2 |
16GB 16GBx2 |
16GB 16GBx2 |
||||
| Data Transfer Bandwidth | 48,000 MB/s (PC5 48000) |
48,000 MB/s (PC5 48000) |
44,800 MB/s (PC5 44800) |
44,800 MB/s (PC5 44800) |
44,800 MB/s (PC5 44800) |
41,600 MB/s (PC5 41600) |
||||
| Voltage | 1.25V | 1.35V | 1.2V | 1.2V | 1.2V | 1.25 V | ||||
| Compatibility | Intel: 600 series, 700 series | |||||||||
| Dimensions | 46.1(H) x 144.2(L) x 7(W)mm | |||||||||
| Warranty | Lifetime warranty | |||||||||
PRECAUTIONS
[1] For more details about how to control the lighting effect by the software(ASUS Aura Sync / GIGABYTE RGB Fusion 2.0 / MSI Mystic Light Sync / ASROCK-Polychrome Sync / BIOSTAR Advanced VIVID LED DJ ), please visit the official website of the software developer(ASUS/GIGABYTE/MSI/ASRock/BIOSTAR)
NOTES
- The frequency and stability of the overclocking memory when automatic reading of the overclocking value (XMP or EXPO) is turned on will vary depending on the difference between the motherboard and CPU. Check "Product Compatibility Inquiry" before purchase for further info
- We reserve the right to modify product specifications without prior notice.
