Supported platforms:
INTEL LGA 1700LGA 115xLGA 1200LGA 2011LGA 2066
AMD AM5 AM4
Specification parameters
Cold discharge: 277mm * 120mm * 27mm
Cold head: 67.5mm * 67mm * 58mm
Water pump parameters
Water pump speed: 3000RPM+10%
Working voltage: DC 12V
Rated current: 0.28+10% A
Operating noise: ≤ 23dB (A)
Water pump interface: 4PIN PWM
Water pump power: ≤ 3.4W
TL-K12 Fan Parameters
Fan size: 120 * 120 * 25MM
Fan speed: 2150RPM+10% (MAX)
Rated current: DC 12V
Fan pressure: 2.87mm H ₂ O (MAX)
Fan air volume: 69CFM (MAX)
Operating noise: ≤ 27dB (A)
Fan interface: 4PIN PWM
ARGB interface:+5V/3PIN
Fan bearing: S-FDB Bearing V2
