TP-Link Deco XE75 Pro AXE5400 三頻 2.5G WAN/LAN Mesh Wi-Fi 6E Router

產品特色

• Whole Home WiFi 6E –覆蓋高達 5,500 ft 2的無縫WiFi ，打造全屋無死角覆蓋†‡
• 全新 6 GHz 頻段 –新世代WiFi頻段，消除所有舊設備的干擾。6GHz 頻段還提供強大的專用回程，進一步優化非 6E設備的WiFi性能△
• 真正的三頻速度 –所有三個WiFi頻段協同工作，為 200 台設備提供高達 5,400 Mbps 的網絡總速度†
• AI-Driven Mesh –將您的家用一個名稱和密碼統一起來，同時在您移動房間時提供最佳連接*
• TP-Link HomeShield –通過網絡和物聯網保護的尖端功能確保您的家庭網絡安全§
• 設置變得比以往更容易 - Deco 應用程序將引導您逐步完成設置
• 通用兼容性 –向後兼容所有WiFi 制式，並適用於任何寬頻服務提供商 (ISP)

產品規格

無線網路

標準:
Wi-Fi 6E

• IEEE 802.11ax 6 GHz
• IEEE 802.11ax/ac/n/a 5 GHz
• IEEE 802.11ax/n/b/g 2.4 GHz

Wi-Fi 速度:
AXE5400

• 6 GHz: 2402 Mbps (802.11ax, HE160)
• 5 GHz: 2402 Mbps (802.11ax, HE160)
• 2.4 GHz: 574 Mbps (802.11ax)

Wi-Fi 範圍:
4-7+ Bedroom Houses (3-pack)
3-5 Bedroom Houses (2-pack)
1-3 Bedroom Houses (1-pack)

• TP-Link Mesh Technology: Optional Ethernet backhaul work together to link Deco units to provide seamless coverage
• AI-Driven Mesh: Intelligently learns the network environment to provide ideal Wi-Fi unique to your home
• 4× High-Gain Antennas (Internal): Multiple antennas form a signal-boosting array to cover more directions and large areas
• Tri-Band: A newly-opened 6 GHz band brings more bandwidth and faster speeds
• Beamforming: Concentrates wireless signal strength towards clients to expand WiFi range

Wi-Fi 容量: Very High

• Tri-Band: Distribute devices to different bands for optimal performance
• 2×2 MU-MIMO: Simultaneously communicates with multiple MU-MIMO clients
• OFDMA: Simultaneously communicates with multiple WiFi 6 clients
• 6 Streams: More than enough bandwidth for connected devices

運作模式:

• Router Mode
• Access Point Mode

硬體規格

處理器: 1.7 GHz Quad-Core CPU
網路孔: 1× 2.5 Gbps Port + 2× Gigabit Ports
*Per Deco Unit: Supports WAN/LAN auto-sensing
按鈕: Reset Button

安全性

Wi-Fi 加密:

• WPA-Personal
• WPA2-Personal
• WPA3-Personal

網路安全性:
SPI Firewall
Access Control
HomeShield Security

• Real-Time IoT Protection
• Malicious Site Blocker
• Intrusion Prevention System
• DDoS Attack Prevention
• Home Network Scanner

訪客網路:

• 1× 6 GHz Guest Network
• 1× 5 GHz Guest Network
• 1× 2.4 GHz Guest Network

軟體

協定:

• IPv4
• IPv6

服務工具: HomeShield
家長監護:
HomeShield Parental Controls

• Custom Profiles
• Professional Content Filter Library
• Family Time
• Bedtime
• Off Time
• Time Rewards
• Family Online Time Ranking
• Pause the Internet
• Weekly and Monthly Reports

WAN 類型:

• Dynamic IP
• Static IP
• PPPoE
• PPTP
• L2TP

服務品質:
HomeShield QoS
QoS by Device
雲端服務:

• OTA Firmware Upgrade
• TP-Link ID
• DDNS

NAT 轉發:

• Port Forwarding
• UPnP

IPTV:

• IGMP Proxy
• IGMP Snooping
• Bridge
• Tag VLAN

DHCP:

• Address Reservation
• DHCP Client List
• Server

DDNS: TP-Link
管理: Deco App

實體

體積:  (W×D×H): 4.1 × 4.1 × 6.7 in (105 × 105 × 169 mm)
包裝內容:
Deco XE75 Pro (3-pack)

1. 3 Deco XE75 Pro units
2. 1 RJ45 Ethernet cable
3. 3 Power adapters
4. 1 Quick Installation Guide

Deco XE75 Pro (2-pack)

1. 2 Deco XE75 Pro units
2. 1 RJ45 Ethernet cable
3. 2 Power adapters
4. 1 Quick Installation Guide

Deco XE75 Pro (1-pack)

1. 1 Deco XE75 Pro units
2. 1 RJ45 Ethernet cable
3. 1 Power adapters
4. 1 Quick Installation Guide

其他規格

認證: CE, FCC, RoHS
環境:

• Operating Temperature: 0°C~40°C (32 °F~104 °F)
• Storage Temperature: -40°C~60°C (-40 °F~140 °F)
• Operating Humidity: 10%~90% RH
• Storage Humidity: 5%~90% RH

測試數據

Wi-Fi 傳輸功率
CE:
<20 dBm (2.4 GHz)
<23 dBm (5 GHz)
<23 dBm (6 GHz)

FCC:
<30 dBm (2.4 GHz)
<30 dBm(5 GHz)
<30 dBm(6 GHz)
